InSinkErator CC101K-8, Programmable Control Panel w/ Automatic Reverse w/ Post Flush, 380-460v

Model Specifics: 380-460v/60/3-ph. For SS-50 to SS-1000 series disposers. Automatic reverse with post flush.

Features:

• Automatic reversing control reverses direction of motor at each startup, increases the cutting element life, and reduces jams
• Reversing delay protects motor from burn out from operator misuse and prevents the motor from reversing while it is in motion
• Post water flush with adjustable timer allows water to run automatically for up to 10 minutes, flushing the disposer and drain lines after the disposer is shut off
• Automatic drop-out system disengages power lines if power loss occurs and must be manually restarted to resume operation
• Timed run or continuous run modes: Timed run shuts off disposer automatically after 10 minutes or can be shut off manuall at any time
• Line disconnect switch with interlock on front cover
• Solenoid valve ensures that water is flowing into the disposer while operating
• Solid state control circuit board with control diagnostic/function lights, delay timers and timed run pin and reversing control
• Solid state control operates on 24v
• Push button ON/OFF switch
• Stainless steel construction is easy to keep clean
• NEMA 4 enclosure

InSinkErator Warranty:

1 Year Parts & Labor
